New Mold Feature ZW3D 2023 – New mode features in xero 3d 2023 there are some new mode features for more detailed design such as the air vent oil groove and engrave
Firstly the air vent pick the parting faces and the parting line, the air vent will be in the preview the space and vent side are customizable you can also enable the level 2 and level 3.
The air vent of this region will be finished in a second repeat the operation for another region in this region there is a hole you can adjust the points location and the vent channel angle to keep distances from the hole between the two cavities you can finish the air vent for two times number under the sizes of level 2 and level 3 can also be customized .
When you create the vane for another cavity it will recognize the existing channel and the stops there after single simplify the eleventh design is finished your groove is everywhere on the mode in this version zebra 3d offers six mainstream types of the audio grooves.
You can set the location the layout and the size of groove the third one is the engrave you can actually create a text shape on the mode plate it is very flexible to adjust the text side and the font you can also generate the slot at the same time these new mode features make more detail design much more automatic.
